Category:Explosives transport vehicle

1. This vehicle is a dangerous goods transport vehicle, specifically an EX/Ⅲ type vehicle; it is used to transport media with individual container (bottle) packaging, with item numbers 1.1B, 1.1G, 1.3C, 1.1D, 1.2D, 1.3C, 1.1C, and 1.4G; the top of the compartment is sealed and cannot be opened. 2. The side/rear protection material is Q235, and the side protection adopts...

Sufficient stock available

A large fleet of specialized vehicles is available for fast delivery!

Delivery time

In-stock vehicles can be delivered within 1-3 days; customized models will be delivered according to the contract timeframe!

Detailed parameters
Product Image Gallery

Main technical parameters
Product Name:	Sinotruk 2-axle explosives transport vehicle
External dimensions:	10500,10400,10200,10000,9800,9400,9200,9000,8800,8450×2550,2500×3998,3950,3900,3800,3700,3500(mm)
Emission levels:	National VI
Cargo box dimensions:	8250,8200,8000,7800,7600,7200,7000,6800,6600,6200×2450,2400,2350×2700,2650,2600,2500,2400,2200(mm)
Total mass:	18000(Kg)
Approach/Departure Angle:	19/8,19/9,19/10,19/11,19/12(°)
Rated weight:	9770,9705,9995,9930(Kg)
Front overhang and rear overhang:	1430/3470,1430/3370,1430/3170,1430/2970,1430/2770,1430/2570,1430/2870,1430/2370,1430/2670,1430/2320(mm)
Curb weight:	8100,7875(Kg)
Maximum speed:	80(km/h)
Chassis parameters
Fuel type:	diesel fuel
Chassis model:	ZZ1187K501GF1
Number of axes:	2
Front track:	1950,2035,1910,1930,2060(mm)
Wheelbase:	3800,4200,4500,4700,5000,5200,5600,5800,4000,5400,6000,3600(mm)
Rear track:	1848,1860,1880(mm)
Number of passengers in the driver's cab:	(people)
Number of leaf springs:	11/9+8,3/9+8,3/3+2,2/3+2,3/-,2/-,2/3,7/7+6,7/7+3,3/7+6,3/7+3,3/3+3,9/9+6,10/9+8,11/-
Number of tires:	6 (items)
Axle load:	6500/11500
Tire specifications:	295/80R22.5 18PR,12R22.5 18PR,11.00R20 18PR,10.00R20 18PR,275/80R22.5 18PR,11R22.5 18PR,295/60R22.5 18PR

Engine parameters
Engine model:	Engine manufacturers	Displacement (ml)	Power (kW) / Horsepower (PS):
WP7H245E62	Weichai Power Co., Ltd.	6800	180/244
WP7H270E62	Weichai Power Co., Ltd.	6800	199/270
WP7H300E62	Weichai Power Co., Ltd.	6800	221/300
MC07.25-61	China National Heavy Duty Truck Group Co., Ltd.	6870	190/258
MC07.27-61	China National Heavy Duty Truck Group Co., Ltd.	6870	202/274
MC07.29-61	China National Heavy Duty Truck Group Co., Ltd.	6870	213/289
WP4.6NQ240E62	Weichai Power Co., Ltd.	4580	177/240
WP5NQ245E62	Weichai Power Co., Ltd.	4580	177/240
MC05H.28-61	China National Heavy Duty Truck Group Co., Ltd.	4910	206/280
MC05H.26-61	China National Heavy Duty Truck Group Co., Ltd.	4910	191/259
MC05H.24-61	China National Heavy Duty Truck Group Co., Ltd.	4910	176/239
WP7H320E62	Weichai Power Co., Ltd.	6800	235/319
WP6T260E62	Weichai Power Co., Ltd.	5496	191/259
WP6T280E62	Weichai Power Co., Ltd.	5496	206/280
WP6T290E62	Weichai Power Co., Ltd.	5496	213/289
WP6T300E62	Weichai Power Co., Ltd.	5496	221/300
WP6T320E62	Weichai Power Co., Ltd.	5496	230/312
WP5H280E62	Weichai Power Co., Ltd.	4950	206/280
WP5H300E62	Weichai Power Co., Ltd.	4950	221/300
WP5H260E62	Weichai Power Co., Ltd.	4950	191/259
MC07.27-60	China National Heavy Duty Truck Group Co., Ltd.	6870	202/274

other
1. This vehicle is a dangerous goods transport vehicle, specifically an EX/Ⅲ type vehicle; it is used to transport media with independent container (bottle) packaging, with item numbers 1.1B, 1.1G, 1.3C, 1.1D, 1.2D, 1.3C, 1.1C, and 1.4G; the top of the compartment is closed and cannot be opened. 2. The side/rear protection material is Q235; the side protection is bolted, and the rear protection is welded; the rear protection section is circular with a diameter of 120mm, and the lower edge is 480mm above the ground; the horizontal length of the retracted tailgate is 300mm, and the tailgate mass is 550kg. 3. Equipped with a speed limiter, limiting the speed to 80km/h; uses only a chassis with a front-mounted exhaust pipe, front disc brakes, and radial tires; equipped with tire blowout emergency protection devices on the steering wheels; uses air suspension on the rear axle; the vehicle is equipped with a driving recorder with satellite positioning function; this vehicle can be optionally equipped with a direct-powered ETC on-board unit. The EBS system controller manufacturer/model is WABCO (Shanghai) Management Co., Ltd./EBS3; only chassis tire models 295/80R22.5 18PR, 275/80R22.5 18PR, 11R22.5 18PR, and 295/60R22.5 are used. 18PR; The corresponding relationship between engine and fuel consumption (L/100km) is as follows: MC07.27-60/26.91, MC07.29-60/26.76, WP4.6NQ220E61/26.07, WP6H245E61/26.32, MC05H.20-60/25.35, MC05H.23-60/25.35, MC05H.25-60/25.35, MC07.25-60/25.57, MC07H.29-60/25.39, WP6H270E61/25.34, WP7H220E62/26.28, WP7H245E62/26.28, WP7H270E62/26.19, W P7H300E62/26.19, MC07.25-61/26.08, MC07.27-61/26.08, MC07.29-61/26.08, WP4.6NQ200E62/25.90, WP4.6NQ220E62/25.90, WP4.6NQ240E62/25.90. 4. Optional: Tailgate without lifting tailgate (without lifting tailgate, rear protective material is Q235, welded connection, cross-section dimensions (height × width) 120mm × 40mm, lower edge ground clearance 480mm); Tailgates from different manufacturers and styles are optional; Cab is optional with chassis; Body exterior is optional; Side door opening type and position is optional; No side door is optional; Rear structure is optional; Fuel tank is optional with chassis.
