Jiangling 2-axle flammable liquid transport van_Flammable liquid transport van_Other models_Product Center_China Truck Show

Jiangling 2-axle flammable liquid transport van

chinatruckplant.com

Category:Flammable liquid transport vehicle

This vehicle is used for transporting dangerous goods. The cargo compartment is sealed at the top and cannot be opened. It is an EX/Ⅲ type vehicle. It transports adhesives, coatings, paint solutions, kerosene, benzene, methanol, ethanol, acetone, toluene, xylene, and paint in individually packaged containers. The category of the transported medium is 3. The hydraulic brake ABS system model is APG3550500A, and the ABS system manufacturer is Zhejiang Asia-Pacific Electromechanical Co., Ltd.

Sufficient stock available

A large fleet of specialized vehicles is available for fast delivery!

Delivery time

In-stock vehicles can be delivered within 1-3 days; customized models will be delivered according to the contract timeframe!

Detailed parameters
Product Image Gallery

Main technical parameters
Product Name:	Jiangling 2-axle flammable liquid transport van
External dimensions:	5995×2160×2800(mm)
Emission levels:	National VI
Cargo box dimensions:	4150×2020×1750(mm)
Total mass:	4495(Kg)
Approach/Departure Angle:	18/15(°)
Rated weight:	1050(Kg)
Front overhang and rear overhang:	1140/1495(mm)
Curb weight:	3250(Kg)
Maximum speed:	80(km/h)
Chassis parameters
Fuel type:	diesel fuel
Chassis model:	JX1041TG26
Number of axes:	2
Front track:	1680,1650,1665,1695(mm)
Wheelbase:	3360(mm)
Rear track:	1570,1604,1585,1620(mm)
Number of passengers in the driver's cab:	(people)
Number of leaf springs:	7/5+6,7/5+6,4/5+6,5/5+6,3/5+6,4/5+4,3/5+4,5/5+4,3/1+3,1/1+1,2/1+2,4/1+3,2/1+1,3/1+2,4/3+2,4/3+3,4/3+4,4/4+2,4/4+3,5/3+2,5/3+3,5/3+4,5/4+2,5/4+3,7/3+2,7/3+3,7/3+4,7/4+2,7/4+3,3/3+2,3/4+2,3/4+3,3/5+2,4/5+2,4/4+4,5/4+4,7/4+4,7/5+4,1/1+3,3/1+1
Number of tires:	6 (items)
Axle load:	1885/2610
Tire specifications:	7.00R16LT 10PR,7.00R16LT 8PR

Engine parameters
Engine model:	Engine manufacturers	Displacement (ml)	Power (kW) / Horsepower (PS):
JX4D25A6H	Jiangling Motors Co., Ltd.	2478	105/142
JX493ZLQ6D	Jiangling Motors Co., Ltd.	2499	90/122
JX495ZLQ6C	Jiangling Motors Co., Ltd.	2478	105/142

other
This vehicle is used for transporting dangerous goods. The cargo compartment is sealed at the top and cannot be opened. It is an EX/Ⅲ type vehicle. It transports adhesives, coatings, paint solutions, kerosene, benzene, methanol, ethanol, acetone, toluene, xylene, and paint in individually packaged containers. The category of the transported medium is 3. The hydraulic brake ABS system model is APG3550500A, manufactured by Zhejiang Asia-Pacific Electromechanical Co., Ltd. The air brake ABS system model is VIE ABS-II, manufactured by [unspecified manufacturer]. Zhejiang Wan'an Technology Co., Ltd.; Engine model and corresponding fuel consumption declaration: JX4D30A6H/11.1L/100km; Protective material: Q235; Connection method: Welded connection for left and right sides and lower rear protection; Rear protection cross-section dimensions (mm): 100×50; Rear protection ground clearance (mm): 400; This vehicle is equipped with a driving recorder with satellite positioning function; It uses only front disc brakes and a chassis with ABS and a front-mounted muffler. It uses radial tires. A speed limiter is installed, limiting the speed to 80km/h. Optional side door type and position: no side door, double side door; optional louvered side panels; optional corrugated board structure. The curb weight includes spare tire, fire extinguisher, and vehicle tools.
