25 cubic meter liquid supply truck
Category:Liquid supply vehicle
1、该车为非危险品运输车.该车主要用途为向井场运送液体并配合压井作业,主要装置为罐体、供液泵。罐体总容量25立方米,有效容积23.83立方米,罐体尺寸(长×长轴×短轴)为(mm):8800×2500×1700。2、侧/后防护装置材料均为Q235;侧/后防护连接...
Sufficient stock available
A large fleet of specialized vehicles is available for fast delivery!
Delivery time
In-stock vehicles can be delivered within 1-3 days; customized models will be delivered according to the contract timeframe!
| Main technical parameters | |||
|---|---|---|---|
| Product Name: | 25 cubic meter liquid supply truck | ||
| External dimensions: | 11900×2550×3400,3730(mm) | ||
| Emission levels: | National VI | ||
| Cargo box dimensions: | ××(mm) | ||
| Total mass: | 31000(Kg) | ||
| Approach/Departure Angle: | 16/9(°) | ||
| Rated weight: | 14820,14755,14365,14300(Kg) | ||
| Front overhang and rear overhang: | 1435/2665(mm) | ||
| Curb weight: | 16050,16505(Kg) | ||
| Maximum speed: | 110,90(km/h) | ||
| Chassis parameters | |||
| Fuel type: | diesel fuel | ||
| Chassis model: | CQ1317HY6Z | ||
| Number of axes: | 4 | ||
| Front track: | 2020/2020,2040/2040,2060/2060(mm) | ||
| Wheelbase: | 2000+4400+1400(mm) | ||
| Rear track: | 1858/1858(mm) | ||
| Number of passengers in the driver's cab: | (people) | ||
| Number of leaf springs: | 10/10/12,9/9/12,8/8/12 | ||
| Number of tires: | 12 (items) | ||
| Axle load: | 6500/6500/18000 (Two-axis set) | ||
| Tire specifications: | 12R22.5 18PR,295/80R22.5 18PR,315/80R22.5 18PR,12.00R20 18PR,11.00R20 18PR | ||
| Engine parameters | |||
|---|---|---|---|
| Engine model: | Engine manufacturers | Displacement (ml) | Power (kW) / Horsepower (PS): |
| SC12E460Q6 | Shanghai New Energy Vehicle Technology Co., Ltd. | 11810 | 338/459 |
| SC12E480Q6 | Shanghai New Energy Vehicle Technology Co., Ltd. | 11810 | 353/480 |
| SC12E420Q6 | Shanghai New Energy Vehicle Technology Co., Ltd. | 11810 | 309/420 |
| SC12E440Q6 | Shanghai New Energy Vehicle Technology Co., Ltd. | 11810 | 323/439 |
| F3GCE611D*M | SAIC Fiat Hongyan Powertrain Co., Ltd. | 11120 | 337/458 |
| F3GCE611E*M | SAIC Fiat Hongyan Powertrain Co., Ltd. | 11120 | 317/431 |
| F3GCE611F*M | SAIC Fiat Hongyan Powertrain Co., Ltd. | 11120 | 295/401 |
| F3GCE611B*M | SAIC Fiat Hongyan Powertrain Co., Ltd. | 11120 | 318/432 |
| other | |||
|---|---|---|---|
| 1、该车为非危险品运输车.该车主要用途为向井场运送液体并配合压井作业,主要装置为罐体、供液泵。罐体总容量25立方米,有效容积23.83立方米,罐体尺寸(长×长轴×短轴)为(mm):8800×2500×1700。2、侧/后防护装置材料均为Q235;侧/后防护连接方式均为螺栓连接+焊接;后防护截面尺寸为120×50mm,离地高度为450mm。3、选装尾部供液口样式和后部爬梯安装位置;选装限速装置,限速装置限速(km/h):90;ABS型号/生产企业:ABS/ASR-24V-4S/4M/东科克诺尔商用车制动系统(十堰)有限公司,CM4XL-4S/4M/广州瑞立科密汽车电子股份有限公司。选装油箱型式位置及后处理样式,选装电瓶箱,储气瓶安装位置。随底盘选装驾驶室,选装走道样式. |
