解放2轴飞机加油车

Jiefang 2-axis aircraft refueling truck

chinatruckplant.com
Category:Aircraft refueling truck

Is the car in stock? : yes

Delivery time Approximately 1-3 days

This vehicle is a hazardous materials transport vehicle, primarily used for refueling small aircraft. It is an FL type vehicle with a total tank capacity of 8.15 cubic meters and an effective tank volume of 7.76 cubic meters. The maximum permitted density of the transported medium (kg/m³) is 800. The tank dimensions (length × major axis × minor axis) (mm) are 3800 × 2050 × 1380. Only a 3900mm axle is used...


Sufficient stock available

A large fleet of specialized vehicles is available for fast delivery!

Delivery time

In-stock vehicles can be delivered within 1-3 days; customized models will be delivered according to the contract timeframe!

Contact Us
Main technical parameters
Product Name:Jiefang 2-axis aircraft refueling truck
External dimensions:6950×2250,2270,2340×2860(mm)
Emission levels:National VI
Cargo box dimensions:××(mm)
Total mass:11995(Kg)
Approach/Departure Angle:20/10(°)
Rated weight:6210(Kg)
Front overhang and rear overhang:1155/1895(mm)
Curb weight:5590(Kg)
Maximum speed:80(km/h)
Chassis parameters
Fuel type:diesel fuel
Chassis model:CA1120P40K59L4BE6A84
Number of axes:2
Front track:1738,1761,1726,1751,1815(mm)
Wheelbase:4200,3900,3600(mm)
Rear track:1678,1740,1690,1752,1800,1812(mm)
Number of passengers in the driver's cab:(people)
Number of leaf springs:3/3+3,3/7+9,3/10+4,7/10+4,7/10+3,3/4+4,3/8+8,3/8+7,3/5+2
Number of tires:6 (items)
Axle load:4360/7635
Tire specifications:245/70R19.5 16PR,8.25R20 16PR,255/70R22.5 16PR
Engine parameters
Engine model:Engine manufacturersDisplacement (ml)Power (kW) / Horsepower (PS):
WP3NQ160E61Weichai Power Co., Ltd.2970118/160
D30TCIF1Kunming Yunnei Power Co., Ltd.2977125/170
CA4DD1-16E6China FAW Group Co., Ltd.3000121/164
CA4DD2-18E6China FAW Group Co., Ltd.3230132/179
CA4DH1-18E6China FAW Group Co., Ltd.3800132/179
YN25PLUS160BKunming Yunnei Power Co., Ltd.2499114/155
CA4DT2-18E68China FAW Group Co., Ltd.2440129/175
YN25PLUS180Kunming Yunnei Power Co., Ltd.2499129/175
CA4DT2A20E610China FAW Group Co., Ltd.2440143/194
other
This vehicle is a hazardous materials transport vehicle, mainly used for refueling small aircraft. The type of hazardous materials transport vehicle is FL, with a total tank capacity of 8.15 cubic meters and an effective tank volume of 7.76 cubic meters. The maximum density of the permitted transport medium (kg/m³) is 800. The tank dimensions (length × major axis × minor axis) (mm) are 3800 × 2050 × 1380. It uses only a chassis with a 3900mm wheelbase. Both side and rear protection are made of aluminum alloy and are bolted together. The rear protection device cross-sectional dimensions (mm) are 100 × 50, and the rear protection ground clearance is 440mm. ABS manufacturer/model: 1. Guangzhou Ruili Kemi Automotive Electronics Co., Ltd./CM4XL-4S/4M; 2. Zhejiang Wan'an Technology Co., Ltd./VIE ABS-II; uses radial tires only, front-mounted exhaust pipe, front disc brakes, speed limiter (80km/h). Equipped with a satellite-based driving recorder, tire blowout protection devices on the steering wheels, and optional direct-powered ETC on-board unit; cab and wheel rim appearance options available with the chassis; different appearance options for the air tanks, fuel tank, battery, and urea tank on both sides of the vehicle, depending on the chassis; optional upper walkway style, optional movable guardrail style, optional upper panel style and rear end panel style; optional different appearance options for the rear safety warning sign and rectangular sign; optional side safety warning sign style; optional rear toolbox style.
