Sinotruk 3-axle vehicle transporter
Category:Car carrier
This vehicle is equipped with a loading platform for transporting and securing vehicles, as well as a device for loading and unloading vehicles. It is mainly used for transporting passenger cars. The side protection device is made of Q235A steel and is connected by bolts. The rear protection is replaced by the vehicle body structure, with a ground clearance of 300mm. The maximum net power of the engine (kW) is MT07.29-60(213). The ABS model and manufacturer are CM...
Sufficient stock available
A large fleet of specialized vehicles is available for fast delivery!
Delivery time
In-stock vehicles can be delivered within 1-3 days; customized models will be delivered according to the contract timeframe!
| Main technical parameters | |||
|---|---|---|---|
| Product Name: | Sinotruk 3-axle vehicle transporter | ||
| External dimensions: | 12000×2550×3730(mm) | ||
| Emission levels: | National VI | ||
| Cargo box dimensions: | ××(mm) | ||
| Total mass: | 24900(Kg) | ||
| Approach/Departure Angle: | 17/6(°) | ||
| Rated weight: | 12970,12905(Kg) | ||
| Front overhang and rear overhang: | 1500/3100(mm) | ||
| Curb weight: | 11800(Kg) | ||
| Maximum speed: | 90(km/h) | ||
| Chassis parameters | |||
| Fuel type: | LNG | ||
| Chassis model: | ZZ1254N56C7F1L | ||
| Number of axes: | 3 | ||
| Front track: | 2050/2050,2070/2070,2080/2080(mm) | ||
| Wheelbase: | 1800+5600(mm) | ||
| Rear track: | 1850,1860,1870(mm) | ||
| Number of passengers in the driver's cab: | (people) | ||
| Number of leaf springs: | 3/3/3+3,7/7/7+5,11/11/11+9 | ||
| Number of tires: | 8 (items) | ||
| Axle load: | 6700/6700/11500 | ||
| Tire specifications: | 295/60R22.5 18PR | ||
| Engine parameters | |||
|---|---|---|---|
| Engine model: | Engine manufacturers | Displacement (ml) | Power (kW) / Horsepower (PS): |
| MT07.29-60 | China National Heavy Duty Truck Group Co., Ltd. | 6870 | 216/293 |
| other | |||
|---|---|---|---|
| The vehicle is equipped with a loading platform for transporting and securing vehicles, as well as a device for loading and unloading vehicles. It is mainly used for transporting passenger cars. The side protection device is made of Q235A steel and is connected by bolts. The rear protection is replaced by the vehicle body structure, with a ground clearance of 300mm. The maximum net power of the engine (kW) is MT07.29-60(213). The ABS model and manufacturer is CM4XL-4S/4M. The manufacturer is Guangzhou Ruili Kemi Automotive Electronics Co., Ltd. The vehicle is equipped with a driving recorder with satellite positioning function. This model can be equipped with a direct-powered ETC on-board unit. Optional exterior styling. |
