7.97 cubic meter concrete mixer truck
Category:cement mixer truck
ABS Model: 3631010-C2000; ABS Manufacturer: Dongke Knorr Commercial Vehicle Braking System (Shiyan) Co., Ltd.; Equipped with a driving recorder with satellite positioning function; Engine Net Power Values: Engine 6K1343N-60, 6K1346N-60, YCK11380N-60, YCK11340N-60, YCK1...
Sufficient stock available
A large fleet of specialized vehicles is available for fast delivery!
Delivery time
In-stock vehicles can be delivered within 1-3 days; customized models will be delivered according to the contract timeframe!
| Main technical parameters | |||
|---|---|---|---|
| Product Name: | 7.97 cubic meter concrete mixer truck | ||
| External dimensions: | 10300×2500,2550×3990(mm) | ||
| Emission levels: | National VI | ||
| Cargo box dimensions: | ××(mm) | ||
| Total mass: | 31000(Kg) | ||
| Approach/Departure Angle: | 20/13(°) | ||
| Rated weight: | 17410(Kg) | ||
| Front overhang and rear overhang: | 1500/2600(mm) | ||
| Curb weight: | 13460(Kg) | ||
| Maximum speed: | 89(km/h) | ||
| Chassis parameters | |||
| Fuel type: | OF | ||
| Chassis model: | DFV1318GP6NJ | ||
| Number of axes: | 4 | ||
| Front track: | 1940/1940,1960/1960,2010/2010,2040/2040,2080/2080(mm) | ||
| Wheelbase: | 1850+3100+1350,1850+3200+1350,1850+3300+1350,1850+3500+1350,1850+3800+1350,1850+4050+1350,1850+4250+1350,1850+4600+1350,1850+4800+1350,1850+3000+1350,1850+2700+1350,1850+2900+1350,1850+2850+1400,1850+3150+1400,1850+3250+1400,1850+3450+1400,1850+3750+1400,(mm) | ||
| Rear track: | 1860/1860(mm) | ||
| Number of passengers in the driver's cab: | (people) | ||
| Number of leaf springs: | 3/3/4,9/9/10,9/9/13,10/10/13,3/3/10,3/3/5 | ||
| Number of tires: | 12 (items) | ||
| Axle load: | 6500/6500/18000 (Two-axis set) | ||
| Tire specifications: | 11.00R20 18PR,12.00R20 16PR,12R22.5 18PR,295/80R22.5 18PR,12.00R20 18PR | ||
| Engine parameters | |||
|---|---|---|---|
| Engine model: | Engine manufacturers | Displacement (ml) | Power (kW) / Horsepower (PS): |
| 6K1343N-60 | Anhui Yichen United Power Technology Co., Ltd. | 12939 | 316/429 |
| YCK11360N-60 | Guangxi Yuchai Machinery Co., Ltd. | 10980 | 265/360 |
| YCK11340N-60 | Guangxi Yuchai Machinery Co., Ltd. | 10980 | 250/340 |
| YCK11380N-60 | Guangxi Yuchai Machinery Co., Ltd. | 10980 | 280/380 |
| 6K1346N-60 | Anhui Yichen United Power Technology Co., Ltd. | 12939 | 339/461 |
| SC12ET440Q6 | Shanghai New Energy Vehicle Technology Co., Ltd. | 11810 | 324/440 |
| SC13ET480Q6 | Shanghai New Energy Vehicle Technology Co., Ltd. | 12820 | 353/480 |
| WP13NG460E61 | Weichai (Weifang) Gas Power Co., Ltd. | 12540 | 338/459 |
| WP13NG430E61 | Weichai (Weifang) Gas Power Co., Ltd. | 12540 | 316/429 |
| WP13NG480E61 | Weichai (Weifang) Gas Power Co., Ltd. | 12540 | 353/480 |
| SC12ET460Q6 | Shanghai New Energy Vehicle Technology Co., Ltd. | 11810 | 338/459 |
| 6K1350N-60 | Anhui Yichen United Power Technology Co., Ltd. | 12939 | 368/500 |
| other | |||
|---|---|---|---|
| ABS Model: 3631010-C2000; ABS Manufacturer: Dongke Knorr Commercial Vehicle Braking System (Shiyan) Co., Ltd.; Equipped with a driving recorder with satellite positioning function; Engine Net Power Values: Engine 6K1343N-60, 6K1346N-60, YCK11380N-60, YCK11340N-60 The maximum net power of the YCK11360N-60 is 310Kw, 333Kw, 275Kw, 245Kw, and 260Kw respectively; Optional features: The cab is optional with the chassis; Main dimensions (section dimensions and ground clearance) of the materials, connection methods, and rear protective devices: Protective material: Q235; Connection method: Bolted connection on the left and right sides, bolted connection to the rear protective device; Rear protective device section dimensions: 120×50mm; Ground clearance (mm): 500mm; Effective tank volume (cubic meters) and tank dimensions (mm): Agitation capacity: 7.97 cubic meters; Agitation capacity, tank installation angle, tank length, and maximum tank diameter: Maximum tank diameter is 2120mm, total tank length (including end caps) is 6396mm; Tank installation angle on the chassis is 14 degrees; Other notes: ETC is optional for this model. The vehicle-mounted device only uses a wheelbase of 1850+3000+1350. |
Product customization
If you cannot find a suitable product, you can also leave us a message and write down the product configuration you need. We will reply to you within 1-2 business days after receiving your message!
