Dongfeng 2-axle detachable garbage truck
Category:garbage truck
1. The vehicle's overall length/wheelbase/curb weight (mm) corresponds to: 6400/3800/6100, 6550/3950/6600; 2. The cab's passenger capacity (persons)/curb weight (kg)/rated payload (kg) corresponds to: 2/6600/5670, 3/6600/5605, 2/6100/6170,...
Sufficient stock available
A large fleet of specialized vehicles is available for fast delivery!
Delivery time
In-stock vehicles can be delivered within 1-3 days; customized models will be delivered according to the contract timeframe!
| Main technical parameters | |||
|---|---|---|---|
| Product Name: | Dongfeng 2-axle detachable garbage truck | ||
| External dimensions: | 6400,6550×2500×3000(mm) | ||
| Emission levels: | National VI | ||
| Cargo box dimensions: | ××(mm) | ||
| Total mass: | 12400(Kg) | ||
| Approach/Departure Angle: | 17/18(°) | ||
| Rated weight: | 5670,5605,6170,6105(Kg) | ||
| Front overhang and rear overhang: | 1250/1350(mm) | ||
| Curb weight: | 6600,6100(Kg) | ||
| Maximum speed: | 88(km/h) | ||
| Chassis parameters | |||
| Fuel type: | OF | ||
| Chassis model: | EQ1120GL6NJ | ||
| Number of axes: | 2 | ||
| Front track: | 1820(mm) | ||
| Wheelbase: | 3800,3950(mm) | ||
| Rear track: | 1800(mm) | ||
| Number of passengers in the driver's cab: | (people) | ||
| Number of leaf springs: | 8/10+7 | ||
| Number of tires: | 6 (items) | ||
| Axle load: | 4300/8100 | ||
| Tire specifications: | 8.25R20,245/70R19.5,9.00R20,8.25R20 14PR,8.25R20 16PR,245/70R19.5 14PR,245/70R19.5 16PR,9.00R20 12PR,9.00R20 14PR,9.00R20 16PR | ||
| Engine parameters | |||
|---|---|---|---|
| Engine model: | Engine manufacturers | Displacement (ml) | Power (kW) / Horsepower (PS): |
| YCS04160N-60 | Guangxi Yuchai Machinery Co., Ltd. | 4156 | 118/160 |
| other | |||
|---|---|---|---|
| 1. The vehicle's overall length/wheelbase/curb weight (mm) correspondence is: 6400/3800/6100, 6550/3950/6600; 2. The cab's passenger capacity (persons)/curb weight (kg)/rated payload (kg) correspondence is: 2/6600/5670, 3/6600/5605, 2/6100/6170, 3/6100/6105; Protective material: Q235A carbon steel; Connection method: Welded connection for left and right sides and lower rear protection; Rear protection cross-section dimensions (mm): 130×60; Rear protection ground clearance (mm): 440; 3. The vehicle is equipped with a driving recorder with satellite positioning; ABS model and manufacturer: 3631010-C2000/Dongke Knorr Commercial Vehicle Braking System (Shiyan) Co., Ltd., J ABS/Jiaozuo Boruike Control Technology Co., Ltd.; 4. The relationship between the engine used and the maximum net power (kw): YCS04160N-60/114kw; 5. This vehicle is used for garbage collection and transportation, and its main special equipment is a hook-lift system. |
Product customization
If you cannot find a suitable product, you can also leave us a message and write down the product configuration you need. We will reply to you within 1-2 business days after receiving your message!
