Dongfeng 1.96 cubic meter sewage suction truck
Category:Sewage suction truck
1、该车用途为吸污,主要装置为污罐。该车仅选用3308mm轴距底盘。介质为液态污物,密度800千克/立方米.罐体总容量1.96立方米,罐体有效容积1.86立方米,罐体外形尺寸(直线段×直径)mm:2600×1050。2、侧,后防护装置材料均为Q235,侧防护螺...
Sufficient stock available
A large fleet of specialized vehicles is available for fast delivery!
Delivery time
In-stock vehicles can be delivered within 1-3 days; customized models will be delivered according to the contract timeframe!
| Main technical parameters | |||
|---|---|---|---|
| Product Name: | Dongfeng 1.96 cubic meter sewage suction truck | ||
| External dimensions: | 5850×1980×2300(mm) | ||
| Emission levels: | National VI | ||
| Cargo box dimensions: | ××(mm) | ||
| Total mass: | 4495(Kg) | ||
| Approach/Departure Angle: | 27.7/13(°) | ||
| Rated weight: | 1495(Kg) | ||
| Front overhang and rear overhang: | 1055/1487(mm) | ||
| Curb weight: | 2870(Kg) | ||
| Maximum speed: | 110(km/h) | ||
| Chassis parameters | |||
| Fuel type: | diesel fuel | ||
| Chassis model: | EQ1045SJ3CDF | ||
| Number of axes: | 2 | ||
| Front track: | 1525,1519,1472,1545,1613,1609(mm) | ||
| Wheelbase: | 2700,2950,3308,3600,2800,2900(mm) | ||
| Rear track: | 1498,1516,1586,1458,1650,1800,1472,1670,1564(mm) | ||
| Number of passengers in the driver's cab: | (people) | ||
| Number of leaf springs: | 6/6+5,3/3+3,2/3+2,5/7+3,5/4+3,6/4+3,6/5+2,6/3+3,3/3,3/3+2,3/6+5,3/8+6,3/5+2,7/10+7,3/4+3 | ||
| Number of tires: | 6 (items) | ||
| Axle load: | 1600/2895 | ||
| Tire specifications: | 6.50R16,7.00R16,7.50R16LT 8PR,6.00R15LT 10PR,6.50R16LT 10PR,7.00R16LT 8PR | ||
| Engine parameters | |||
|---|---|---|---|
| Engine model: | Engine manufacturers | Displacement (ml) | Power (kW) / Horsepower (PS): |
| D20TCIF1 | Kunming Yunnei Power Co., Ltd. | 1999 | 93/126 |
| Q28-130E60 | Anhui Quanchai Power Co., Ltd. | 2800 | 96/130 |
| CA4DB1-13E6 | China FAW Group Co., Ltd. | 2207 | 95/129 |
| D20TCIF11 | Kunming Yunnei Power Co., Ltd. | 1999 | 93/126 |
| YCY24140-60 | Guangxi Yuchai Machinery Co., Ltd. | 2360 | 103/140 |
| CY4BK161 | Dongfeng Chaoyang Chaichai Power Co., Ltd. | 3856 | 105/142 |
| ZD30D16-6N | Dongfeng Light Engine Co., Ltd. | 2953 | 120/163 |
| CY4BK461 | Dongfeng Chaoyang Chaichai Power Co., Ltd. | 3707 | 95/129 |
| M9T-600 | Dongfeng Light Engine Co., Ltd. | 2298 | 105/142 |
| Q23-136E60 | Anhui Quanchai Power Co., Ltd. | 2300 | 100/136 |
| Q23-132E60 | Anhui Quanchai Power Co., Ltd. | 2300 | 97/131 |
| Q25-152E60 | Anhui Quanchai Power Co., Ltd. | 2493 | 112/152 |
| YN25PLUS160B | Kunming Yunnei Power Co., Ltd. | 2499 | 114/155 |
| D20TCIF61 | Kunming Yunnei Power Co., Ltd. | 1999 | 103/140 |
| YCY24155-61A | Guangxi Yuchai Machinery Co., Ltd. | 2360 | 113/153 |
| ZD25D16-6D | Dongfeng Light Engine Co., Ltd. | 2499 | 120/163 |
| Q25N-152E60 | Anhui Quanchai Power Co., Ltd. | 2496 | 112/152 |
| Q25D-162E60 | Anhui Quanchai Power Co., Ltd. | 2496 | 116/157 |
| Q25A-150E60 | Anhui Quanchai Power Co., Ltd. | 2496 | 110/149 |
| Q23D-143E60 | Anhui Quanchai Power Co., Ltd. | 2300 | 103/140 |
| D2.5NS6B185H | Dongfeng Cummins Engine Co., Ltd. | 2498 | 136/184 |
| other | |||
|---|---|---|---|
| 1、该车用途为吸污,主要装置为污罐。该车仅选用3308mm轴距底盘。介质为液态污物,密度800千克/立方米.罐体总容量1.96立方米,罐体有效容积1.86立方米,罐体外形尺寸(直线段×直径)mm:2600×1050。2、侧,后防护装置材料均为Q235,侧防护螺栓连接,后防护焊接,截面尺寸为100×50mm,离地高度为400mm。3、ABS型号/厂家:ABS/ASR-12V-4S/4M/襄阳东风隆诚机械有限责任公司。选装前面罩,前保险杠,前组合灯具。随底盘选装左右油箱位置。 |
