Dongfeng 11.18 cubic meter water sprinkler truck
Category:sprinkler
Effective tank volume: 11.18 cubic meters; Corresponding dimensions of length (mm)/wheelbase (mm)/rear overhang (mm)/tank dimensions (length × major axis × minor axis) (mm): 7600/3950/2390/4500×2300×1550, 8200/4500/2440/4900×2300×1480; 8400/470...
Sufficient stock available
A large fleet of specialized vehicles is available for fast delivery!
Delivery time
In-stock vehicles can be delivered within 1-3 days; customized models will be delivered according to the contract timeframe!
| Main technical parameters | |||
|---|---|---|---|
| Product Name: | Dongfeng 11.18 cubic meter water sprinkler truck | ||
| External dimensions: | 8400,8200,7600×2500×3200,3350(mm) | ||
| Emission levels: | National VI | ||
| Cargo box dimensions: | ××(mm) | ||
| Total mass: | 18000(Kg) | ||
| Approach/Departure Angle: | 19/16,19/17(°) | ||
| Rated weight: | 10650(Kg) | ||
| Front overhang and rear overhang: | 1260/2440,1260/2390(mm) | ||
| Curb weight: | 7155(Kg) | ||
| Maximum speed: | 105(km/h) | ||
| Chassis parameters | |||
| Fuel type: | diesel fuel | ||
| Chassis model: | EQ1185LJ9CDE | ||
| Number of axes: | 2 | ||
| Front track: | 1862,1933,1949,1904,1960(mm) | ||
| Wheelbase: | 3600,3950,4500,4700,5000,5300,5600(mm) | ||
| Rear track: | 1806,1865(mm) | ||
| Number of passengers in the driver's cab: | (people) | ||
| Number of leaf springs: | 8/10+7,8/-,7/7+3,6/7+3 | ||
| Number of tires: | 6 (items) | ||
| Axle load: | 6500/11500 | ||
| Tire specifications: | 295/80R22.5 18PR,10.00R20 18PR,275/80R22.5 18PR | ||
| Engine parameters | |||
|---|---|---|---|
| Engine model: | Engine manufacturers | Displacement (ml) | Power (kW) / Horsepower (PS): |
| CY4SK761 | Dongfeng Chaoyang Chaichai Power Co., Ltd. | 4087 | 145/197 |
| YCS04200-68 | Guangxi Yuchai Machinery Co., Ltd. | 4156 | 147/199 |
| D4.5NS6B220 | Dongfeng Cummins Engine Co., Ltd. | 4500 | 162/220 |
| B6.2NS6B210 | Dongfeng Cummins Engine Co., Ltd. | 6200 | 154/209 |
| B6.2NS6B230 | Dongfeng Cummins Engine Co., Ltd. | 6200 | 169/229 |
| D4.0NS6B195 | Dongfeng Cummins Engine Co., Ltd. | 4000 | 143/194 |
| D45TCIF1 | Kunming Yunnei Power Co., Ltd. | 4461 | 162/220 |
| B6.2NS6B260 | Dongfeng Cummins Engine Co., Ltd. | 6200 | 191/259 |
| D4.5NS6B240 | Dongfeng Cummins Engine Co., Ltd. | 4500 | 176/239 |
| other | |||
|---|---|---|---|
| Effective tank volume: 11.18 cubic meters; Corresponding dimensions of the external dimensions (length (mm)/wheelbase (mm)/rear overhang (mm)/tank dimensions (length × major axis × minor axis) (mm): 7600/3950/2390/4500×2300×1550, 8200/4500/2440/4900×2300×1480; 8400/4700/2440/5000×2300×1450; ABS system manufacturer, model: Jiaozuo Boruike Control Technology Co., Ltd., J ABS; Side protection device material: Q235, connection method: welding; Rear underrun protection device material: Q235, connection method: welding, cross-sectional dimensions (width × height): 50 × 120 (mm), ground clearance: 490mm. This vehicle is equipped with a tank, water pump, and nozzles, mainly used for spraying roads, serving as a dust suppressant and coolant. |
Product customization
If you cannot find a suitable product, you can also leave us a message and write down the product configuration you need. We will reply to you within 1-2 business days after receiving your message!
